Model | HW160Ai | HW180Ai | |
Frequency(Hz) | 50/60 | 50/60 | |
Rated output(KW) | 0.8 | 3.0 | |
Max.output(KW) | 1.0 | 3.2 | |
Rated voltage (V) | 220,230 | 220,230 | |
Power factor (cos) | 1 | 1 | |
Welding type | Manual arc welding | Manual arc welding | |
Welding voltage(V) | 28-70 | 28-70 | |
Welding current(A) | 130 | 150 | |
Diameter of welding rod (mm) | 2.0-4.0 | 2.0-4.0 | |
Loading continuous rate (%) | 60 | 60 | |
Engine model | HS170F | HS170F | |
Engine type | OHV, single cylinder, 4 stroke, air cooling | ||
Displacement(cc) | 208 | 208 | |
Max.output(HP/rpm) | 7.0/3600 | 7.0/3600 | |
Ignition mode | Transistorized Magneto | Transistorized Magneto | |
Starting mode | Recoil | Recoil | |
Fuel tank capacity (L) | 9 | 9 | |
Oil capacity(L) | 0.6 | 0.6 | |
Continuous work time(h) | 8 | 8 | |
Noise(dB)(7m) | 67 | 67 | |
Dimensions(mm) (L*W*H) | 505*405*465 | 505*405*465 | |
Net weight(kgs) | 30 | 34 | |
Gross weight(kgs) | 32 | 36 |
